Universal Walking Foot / Even Feed - 5mm Width - Low Shank

This universal replacement walking foot (even feed foot) fits hundreds of low shank sewing machines across multiple brands. Designed for machines with a maximum 5mm zigzag stitch width and front-loading bobbin case. Includes guide bar for quilting and topstitching. Compatible with part #214875014.

What's Included

• Universal walking foot / even feed foot
• Guide bar - For consistent seam spacing and quilting

IMPORTANT: 5mm Width Compatibility

This walking foot is designed for machines with a MAXIMUM 5mm zigzag stitch width.

⚠️ WARNING: If your machine has a 7mm or 9mm maximum zigzag width, this foot may NOT fit properly. Using a walking foot that is too narrow for your machine can result in the needle hitting the foot, causing broken needles, damaged foot, or injury. Always verify your machine's maximum zigzag width before purchasing.

How to check your machine's zigzag width: Set your machine to the widest zigzag stitch setting. If it goes wider than 5mm, you need a 7mm or 9mm walking foot instead.

Key Features

• 5mm width - For machines with 5mm max zigzag stitch
• Universal compatibility - Fits Brother, Janome, BabyLock, Elna, Juki, Kenmore, Singer, Viking, and more
• Low shank design - Fits most low shank machines with front-loading bobbin
• Even feed system - Top and bottom layers feed evenly together
• Guide bar included - Maintains consistent spacing for quilting
• Prevents fabric shifting - Keeps layers aligned perfectly

Perfect For

• Quilting - Keeps all layers moving together, guide bar ensures even spacing
• Matching plaids and stripes - Prevents pattern misalignment
• Fabrics with nap or pile - Velvet, corduroy, fleece
• Multiple fabric layers - Prevents top layer from shifting
• Difficult fabrics - Slippery, stretchy, or uneven materials
• Topstitching parallel seams - Guide bar maintains consistent spacing
• Preventing puckering - Smooth, even seams

How It Works

The walking foot has feed dogs on top that work in sync with your machine's bottom feed dogs. This dual-feed system grips fabric from both top and bottom, ensuring all layers move through the machine at the same rate. This prevents the top layer from shifting, bunching, or slipping - essential for quilting, matching plaids, and working with fabrics that have nap or pile.

The included guide bar attaches to the walking foot and helps you maintain consistent spacing between rows of stitching - perfect for quilting, topstitching parallel seams, and creating evenly-spaced decorative stitching.

Compatible Brands & Models

This universal walking foot fits hundreds of low shank sewing machines with 5mm maximum zigzag width and front-loading bobbin case, including:

BabyLock: BL16, BL18, BL20A, BL22, BL23, BL30A, BL37, BL40, BL40A, BL66, BL67, BL80B, BL137A, BL200A, BL2160, BL6150, BL6200, BL6300, BL6600, BL6700, BL6800, BL7800, BLCC, BLCC2, BLDC, BLDC2, BLG, BLG2, BLG3, BLL, BLL2, BLMY, BLN, BLQC, BLQC2, BLR, BLR2, BLR3, BLSO, BLSOG, BLSR, BLSY, BLTP, ESE, ESE2, ESG, ESG2, ESG3, ESI, ESI2, ESN, ESP, INT and more

Brother: BC1000, BC2100, BC2500, BM2700, BM2700AS, BM3600, CE4000, CE5000, CE5000PRW, CE5500, CE5500PRW, CE8080PRW, CE8100, CP6500, CP7500, CS100T, CS4000, CS5055PRW, CS6000, CS6000B, CS6000I, CS6000T, CS770, CS80, CS8060, CS8070, CS8072, CS8080, CS8120, CS8130, CS8150, CS9100, DS120, DS140, DZ2400, DZ2750, DZ3000, DZ3400, DZ820E, ES2000, HC1850, HE120, HE240, HS1000, HS2500, HS3000, HS9500, Innov-is V3, V5, V7, LB6770PRW, LB68000PRW, LS2000, LS2020P, LS2250PRW, LS2300PRW, LS2320, LS2350, NQ700, NQ900, NQ1300, NQ3500D, NV200, NV350SE, NV400, NV600, NV900D, NV1000, NV1200, NV1250D, NV1500, NV1500D, NV2500D, NV2800D, NV4000D, NV4500D, NV6700D, NX200, NX250, NX400, NX400Q, NX450, NX450Q, NX5000, NX600, NX650, NX650Q, NX800, PC210, PC210PRW, PC2800, PC3000, PC4000, PC420, PC420PRW, PC5000, PC6000, PC6500, PC7000, PC7500, PC8200, PC8500 and more

Elna: 1000, 2100, 2110, 2130, 2300, 2600, 2800, 3210, 3230, 5100, 6001, 6003, 6004, 6005, 6200, 6600, 7200, 9500, Q6600, Sew Fun, Sew Green, Sew Zebra

Janome / New Home: 100, 105, 106, 108, 110, 128, 200, 300, 311, 344, 352, 372, 373, 392, 393, 405, 415, 419S, 423S, 436, 444, 446, 532, 534, 535, 540, 541, 542, 543, 544, 545, 552, 556, 574, 592, 605, 608, 609, 611, 618, 619, 620, 622, 623, 624, 625FA, 626, 628, 632, 640, 641, 642, 655, 656A, 656B, 657, 657A, 660 Jem Gold, 670, 672, 692, 792, 808, 844, 900, 910, 920, 980, 990, 1004, 1008, 1014, 1017, 1018, 1018S, 1022, 1304, 1306, 1308, 1310, 1312, 1504, 1506, 1508, 1510, 1512, 1518, 1550, 1560, 1570, 1571, 1580, 1580LX, 1585, 1612, 1622, 1714, 1722, 1780, 1803, 1804, 1806, 1810, 1812, 1814, 1816, 1818, 1822, 1918, 2003, 2003P, 2039, 2041, 2206, 2212, 2222, 3012, 3016, 3022, 3125, 3128, 3822, 4612, 7306 Magnolia, 11558, 41012, Combi, Combi-10, ENX24, HD1000, Hello Kitty models, HF107, J3-18, J3-20, J3-24, JB1406, JB1408, JB1410, JR1012, JS1008, JW5622, L-393, NOV3000, NOV4000, RX18s, Schoolmate S-3015, TB12, TB30, XL11 and more. Fits all Janome low shank machines with front-loading bobbin case and 5mm max zigzag width.

Juki: HZL-E61, HZL-E70, HZL-E71, HZL-E80

Kenmore: 385.16524000, 385.1712490, 385.19150090

Necchi: EV7, FA16, TM8

Simplicity: SL300

Singer: 7463, 7469, 7469Q, 8763, SES-1000

Viking: 207, 215, 219, 224, E10, E20, C10, C20

And many more low shank machines with 5mm max zigzag width and front-loading bobbin case.

Replacement Alternative

This is a replacement walking foot, not a genuine brand-name part. It's designed to fit hundreds of low shank sewing machines across multiple brands, offering excellent value for quilters and sewers who need even feed capability without the premium price of genuine parts.

An essential accessory for any quilter or sewer working with challenging fabrics. This universal walking foot with guide bar will transform your quilting and ensure professional results every time.
